Economic Car DVR 4 Channel Full HD , High Definition 12 Volt DVR Systems

    Buy cheap Economic Car DVR 4 Channel Full HD , High Definition 12 Volt DVR Systems from wholesalers

    Buy cheap Economic Car DVR 4 Channel Full HD , High Definition 12 Volt DVR Systems from wholesalers
    • Buy cheap Economic Car DVR 4 Channel Full HD , High Definition 12 Volt DVR Systems from wholesalers
    • Buy cheap Economic Car DVR 4 Channel Full HD , High Definition 12 Volt DVR Systems from wholesalers
    • Buy cheap Economic Car DVR 4 Channel Full HD , High Definition 12 Volt DVR Systems from wholesalers
    • Buy cheap Economic Car DVR 4 Channel Full HD , High Definition 12 Volt DVR Systems from wholesalers
    • Buy cheap Economic Car DVR 4 Channel Full HD , High Definition 12 Volt DVR Systems from wholesalers

    Economic Car DVR 4 Channel Full HD , High Definition 12 Volt DVR Systems

    Ask Lasest Price
    Brand Name : VisionMaster
    Model Number : VM-1504-HD
    Price : Negotiable
    Certification : CE,FCC
    Payment Terms : T/T, Western Union,PayPal
    Supply Ability : 2000 sets / month
    Delivery Time : 3-5 work days for samples,15-30 work days for large orders
    • Product Details
    • Company Profile

    Economic Car DVR 4 Channel Full HD , High Definition 12 Volt DVR Systems

    Economic Car DVR 4 Channel Full HD , High Definition 12 Volt DVR Systems

    VISIONMASTER PRODUCTS' Advantages :


    1. Power failure protection.

    2. Wide voltage (8-36V)

    3. OTA function support. (Upgrating DVR software automatically, better after-sales service for you.
    4. A SMS can get DVR situation feedback from DVR

    5. Industrial level design. (More professional and better quality.)
    6. Modular design. (To prevent a module error while affecting the entire product.)
    7. Encrypt video format. (To prevent data loss)
    8. Current and voltage over protection.
    9. Wide working temperature. (-25°C- +75°C).
    10. Data redundancy technology. (To prevent data loss)
    11. Excellent vibration protection.

    SystemLanguageEnglish / Chinese
    Operation InterfaceGraphical User Interface (OSD menu)
    Password Security2 Levels: Administrator or User
    VideoVideo InputSupports 4 channels CIF/HD1/D1/960H/720P AHD camera Video input
    Supports 2-CH 720P AHD + 2-CH 960H analog mixing Video input
    Supports 1-CH 720P/1080P IPC + 4-CH 960H/D1/CIF Video input
    Note: 4 channels 720P AHD or 1-CH 720P/1080P IPC + 4-CH 960H Video input will require high speed SD card ( > 80Mb/S, Class 10 or higher)
    Video Output2 Channels (Front Panel 3.5mm Jack, Rear Panel on 24 pin I/O Port )
    Video DisplaySingle picture, 1~5 pictures
    Signal SystemPAL / NTSC ( PAL@100 frame 720P/sec; NTSC@120 frame 720P/sec )
    Image CompressionH.264 Main profile
    AudioAudio Input4 Channels
    Audio Output2 Channels (Front Panel 3.5mm Jack, Rear Panel on 24 pin I/O Port )
    Recording FormatSynchronized A/V recording
    Recording & StorageImage ResolutionCIF / HD1 / D1 / 960H / 720P/1080P optional
    Video CodingISO14496-10 Industry Standard
    Video Bit RateCIF: 1536Kbps ~ 128Kbps,
    HD1/D1: 2048Kbps ~ 400Kbps,
    960H: 2048Kbps ~ 400Kbps,
    720P:4096Kbps ~ 400Kbps
    1080P:4096Kbps ~ 400Kbps
    Select from 8 Levels of Video Image Quality ranging from 1(Highest) to 8(Lowest)
    Audio Bit Rate40Kbps
    Storage2 SD Card Slots, Up to 128GB each, Class 10 or higher

    Product Description

    Features Details:

    Ø HIS Solution,H.264 Compression Mode, Many stream recording,4CH Video+4CH Audio Input, Compatible with 720P/960P Mega Pixels AHD High Definition and Standard Definition Analog Camera input.

    Ø Real-time HD Video Recording, 720P/D1/HD1/CIF for Optional,Adjustable Frame Rate Quality.

    Ø Professional Power Design for all kinds of Vehicles, 10-36V DC

    Ø Wide Voltage, Over-load,Over-voltage,Short Circuit,Reverse Protection,Suitable for all kinds of vehicles.

    Ø Support DC 12V/2.5Amp output, it can offer power for cameras,mini monitor and some peripheral device.

    Ø SD card Data record storage (2 SD cards,Each maximum support 128GB ) It can be completely resist car Vibration,Dust and others cause data corruption;

    Ø Watchdog Abnormal will trigger Restart Protection Function . It can better protect Device and Video.

    Ø Exclusive pre-allocate DVR Special File System Technology,Solving repeatedly wipe cause file fragmentation, and ensure the integrity of the data.

    Ø Flame out Time-lapse Video Recording Function ( Highest support long delay time 24 hours.)

    Ø Auto Recording,Time Recording,Alarming Recording Modes for Different Request.

    Ø Display vehicle traffic status, Vehicle numbers ,Route, Super-low speed vehicle Information, Convenient management.

    Ø Support GPS/BD,Gsensor Modules Extension.

    Ø 4CH alarm inputs (Doors, lights, steering, braking, reversing and all types can be configured), Can support kinds of response linkages.

    Ø 1CH alarm output.

    Ø All Aviation connectors, Super stable, High Anti-shock,Easy installation Plug in and out.

    Ø Fluent system interface is intuitive and perfect

    Ø Support SD card Remote Software Upgrade

    Ø Can be batch functional customization according to customer's requirements;

    Ø Dimension and Weight
