Ship / Home 4G Mobile DVR With GPS , 720P 4ch Camera Dvr Kit Customized Language

Ask Lasest Price
Brand Name :	VisionMaster
Model Number :	VM-1504-HD
Price :	Negotiable
Certification :	CE,FCC
Payment Terms :	T/T, Western Union,PayPal
Supply Ability :	2000 sets / month
Delivery Time :	3-5 work days for samples,15-30 work days for large orders

Add to Cart

Product Details
Company Profile

Ship / Home 4G Mobile DVR With GPS , 720P 4ch Camera Dvr Kit Customized Language

Product Description

VM-1504-HD is Mega Pixels HD Multi-Functional Mobile DVR .H.264 compression mode ,support 4ch realtime 720P Mega Pixels AHD input and Analog satandard defition camera input; Exclusive pre-allocate DVR Special File system Technology ,Solving repeatedly wipe cause file fragmentationsolving SD card file system collapse data loss and can not find SD card and file garbled ,ensure the integrity of the data .

Item	Parameter
Mode	VM-1504-HD
Os	Linux
Language	chinese/English/Customized
Video compression	H.264
GUI	Setup system parameters with the remote control
Video record system	video input	4CH 720P AHD input,aviation connector
	video output	1 CVBS,Aviation,Support 1CH Full Screen,4CH Screen
	preview	Support 1 channel and 4 channels preview.Support Manual/Alarm Trigger fullscreen preview
	resolution	720P/D1/HD1/CIF MAX:4 channels of 720P and 4 channels of D1
	video quality	1-4 levels ,1 is the highest level
	viedo standard	P/N/CIF/HD1/D1/720P
	record mode	auto recording after power on/ Timed recording/alarm trigger recording/ manual recording
Audio	audio input	4ch aviation plug
Audio	audio output	1ch aviation plug
Alarm	alarm input	4ch Alarm Input, kinds of alarm linkage support
Alarm	alarm output	1ch Alarm Output
Multi-funtion	Gps /3G/4G/WIFI/G-sensor
Storge capacity	dual SD Card,each max 128GB SD Card loop recording
Video palyback	Max support 4CH Replay /Stop/Fast/Slow at same time
Video palyback	support forward and backward play at the speed of: x 2,x4,x8,x16
Voltage & Power	voltage Input	DC:+10V ~ +36V
	voltage output	+12V/2.5A, +5V/2.5A
	power consumption	Normal working < 5w
Working Environment	temperature:-20℃ to +70℃////humidity:20% to 80%
Security	User/Admin 2 Level Different Password
Size/ Net Weight	112(W) x36(H) x138(D) mm////360g

FAQ

Q:When Device issue appear,you are confused on how to solve it.
A:Check Device Item No & Firmware Version,sent back to us with detail description of issue.Our

Technical Team will handle it.More detail you described,easier for us to solve it quickly

Q: When SD card and HDD records, How is the record coverage?
A: SD card and HDD will record circularly for each other. When they are full, they will delete the

original video records respectively.

Q: Can’t playback files on PC successfully?
A: Possible reason is as follows:

1.Have never chosen a record file or document path; please choose the path that records file first

before playback.

HD 720P 4ch cctv camera dvr kit with optional LCD 3G and Wi-Fi
