| Item | Parameter |
| OS | Linux |
| Language | Chinese/English/Others (can be customized) |
| Video Compression | H.264 Compression Mode |
| OSD | Overlays information such as date time and vehicle ID |
| GUI | Graphical User Interface | Can connect to external LED screen. Setup system parameters with
the remote control. |
| Video Record System | Video Input | 8CH 720P AHD/8CH 1080P AHD input ,aviation connector. |
| Video Output | 1CH CVBS+ VGA output for optional, 1.0Vp-p, 75Ω,Aviation |
| Preview | Support 1 / 2 / 4 / 5 / 6 / 8 / 9 channels preview.,Support
Manual/Alarm Trigger full screen preview |
| Resolution | Support 1080P/720P/D1/CIF, MAX:8 channels 1080P |
| Video Quality | 0-7 levels, 0 is the highest level, 7 is the lowest level. |
| Video Standard | PAL: 100f/s , CCIR625 line,50field;
NTSC: 120f/s, CCIR525 line,60field;
CIF: 256Kbps ~ 1.5Mbps, multi levels video quality optional;
HD1: 600Kbps ~ 2.5Mbps, multi levels video quality optional;
D1: 800Kbps ~ 3Mbps, multi levels video quality optional;
720P : 1Mbps~4Mbps, multi levels video quality optional;
1080P: multi levels video quality optional; |
| Record Mode | The default setting is auto recording after power on. Timed
recording, alarm trigger recording and manual recording are
supported. |
| Audio | Audio Input | 9CH ,Aviation Plug |
| Audio Output | 2CH,Front port is earphone port ,rear port connects to BNC
connector. |
| Compression | G.726 compression, 8KB/s speed |
| Alarm Input | 16CH IO Alarm Input, 2CH AD input, pulse speed input; Support alarm
linkage function |
| Alarm Output | 4CH Relay Alarm Output, Support the linkage acousto-optic alarm,
cut off fuel oil/power,etc |
| Communication Interface | 2CH RS232, support extension device, such as POS machine, Oil Feul
sensor, LED advertising screen , etc. |
| 2CH 485 interface, can connect PTZ,etc. |
| 2CH CAN interface. |
| Wireless transfer | Support Built-in 3G network, WCDMA,CDMA2000,TD-SCDMA compatible
with GPRS,EDGE; Support Built-in 4G network, TTD-LTE, FDD-LTE |
| Position | Support Built GPS/BD Module,can make playback analysis of vehicle
routing |
| G-Sensor | Support G-sensor |
| Video Storage | Storage | 2.5’’ HDD+ SD Card,each max 2TB HDD + 128GB SD Card mirror
recording to protect data from loss |
| Upgrade | Support USB flash disk updating,SD card upgrade , OTA remote
upgrade automatically |
| File Format | .264 |
| File System | Special Car system File System |
| USB | Front panel supports USB port, support USB flash disk upgrade to
backup; hard disk box USB port, can back up video data |
| Video Playback | Video Search | Search video by Record Time/Record Type etc |
| Playback | Max support 8CH Replay /Stop/Fast Forward/Fast Reverse at same time |
| Support x 2,x4,x8,x16. fast forward or fast backward play |
| Print Mode | thermosensitive |
| Print Speed | 30mm／second |
| Print width | 57.5±0.5mm |
| Resolution | 8 points per millimeter |
| Print Paper width | ≤57.5±0.5mm |
| Safety Management | User/Admin 2 Levels Different Passwords , support screen lock |
| Voltage & Power Consumption | Power Management | Adaptive wide power input, support Wide Voltage,
Over-load,Over-voltage,Short Circuit,Reverse Protection..Support
Time Setting/Delay power off |
| Voltage Input | DC:+8V ~ +36V |
| Voltage Output | +12V@2.5A,+5V@2.5A |
| Power-off Protection | UPS Technology,All video information can be saved automatically
when the power is cut off, and make sure that all the files can not
be damaged. |
| Power Consumption | Normal Working ＜10W |
| Working Environment | Temperature | -20℃ to +70℃ |
| Humidity | 20% to 80% |
| others | Size | 180mm*53mm*170mm |
| Net Weight | ≤850g |
